Shackle Insulator

Shackle Insulators are made available by us in a wide range of sizes and other specifications. All the components and materials used in the manufacturing of Shackle Insulators are of high quality, which results in excellent insulation in various applications.

Shackle Insulator

We excel in manufacturing high quality Ceramic Shackle Insulator. These shackle insulators cater to the needs of the clients at the national standard. Our range of shackle insulators are used in 1.1 kV Line for various industries. We seek to ensure our clients contentment by providing them high quality Shackle Insulator.

Sizes
  • 1.Type-I (90 X 75)
  • 2.Type-II (100 X 115)
Features
  • 1.Heavy insulated glaze & smooth coating
  • 2.More effective during the heavy rain fall
  • 3.High performance
  • 4.Long service life.
  • 5.Available in brown color and HDP packaging.
  • 6.Manufactured and designed as per IS: 1445/1977
Used in Industries
  • 1.Turnkey projects
  • 2.Line Works
  • 3.Transmissions
  • 4.Sub-station projects
Technical Specifications

Power Frequency Flash over Voltage (Dry)

25 kV

Power Frequency Flash over Voltage (Wet)

10 kV

One Minute Power Frequency Withstand Voltage (Dry)

23 kV

One Minute Power Frequency Withstand Voltage (Wet)

10 kV

Power Frequency Puncture Withstand Voltage

35 kV

Minimum Failing Load

11.5 KN

Marking

Rashtriya INDIA, Month & Year

Shackle Insulator

We offer an deal in wide range of LT Shackle Insulator. All the components and materials used in the manufacturing of LT Shackle Insulators are of high quality, which results in excellent insulation in various applications.
